DS-2CD1047G2-L(UF) 4 MP ColorVu MD 2.0 Fixed Bullet Camera

DS-2CD1047G2-L(UF) 4 MP ColorVu MD 2.0 Fixed Bullet Camera

Name: DS-2CD1047G2-L(UF) 4 MP ColorVu MD 2.0 Fixed Bullet Camera
SKU: 5294
Availability: InStock

Model: DS-2CD1047G2-LUF (4MP Bullet)

~~₨13,000.00~~ ₨12,956.00

Add to wishlist Compare

Order on WhatsApp

Other people want this. 19 people have this in their carts right now.

Categories: ALL TECH ACCESSORIES, Camera & Securities, ColorVu Lite Network Camera Tags: 24/7 color imaging, Built-in microphone for real-time audio security, Support Human and Vehicle Detection, up to 256GB (SD card slot) (Optional), Water and dust resistance (IP67)

24/7 colorful imaging
Support Human and Vehicle Detection
Water and dust resistant (IP67)

Reviews

There are no reviews yet.

Be the first to review “DS-2CD1047G2-L(UF) 4 MP ColorVu MD 2.0 Fixed Bullet Camera”

Description

DS-2CD1047G2-L(UF) – 4 MP ColorVu MD 2.0 Fixed Bullet Network Camera

The DS-2CD1047G2-L(UF) is a 4 MP ColorVu MD 2.0 Fixed Bullet Network Camera designed to provide exceptional surveillance day and night. With 24/7 colorful imaging, it offers high-quality video in both well-lit and low-light environments. The camera’s advanced 120dB WDR (Wide Dynamic Range) ensures that you get clear, detailed images even in difficult lighting situations, such as backlighting.

Equipped with human and vehicle detection, this camera enhances security by automatically recognizing and tracking important objects. The camera’s H.265+ compression technology allows for more efficient storage and bandwidth usage, ensuring you can store more footage without compromising quality.

Key Features of DS-2CD1047G2-L(UF)

4 MP resolution for crisp and clear video
24/7 colorful imaging ensures vibrant and detailed images at all times
Human and vehicle detection for improved security monitoring
120dB WDR enhances image quality in difficult lighting conditions
Efficient H.265+ compression reduces storage and bandwidth usage
IP67-rated for water and dust resistance, perfect for outdoor use
On-board storage supports up to 256 GB via SD card slot (optional)
Built-in microphone (optional) for real-time audio monitoring
1/3″ Progressive Scan CMOS sensor for excellent image clarity
Maximum resolution of 2560 × 1440 for detailed footage
Smart IR lighting for enhanced night vision up to 30 meters

Why Choose the DS-2CD1047G2-L(UF)?

The DS-2CD1047G2-L(UF) is an ideal choice for those looking for reliable, high-quality surveillance. Its 4 MP resolution ensures sharp and detailed video, while 24/7 colorful imaging guarantees that you won’t miss any critical moments. The 120dB WDR and human and vehicle detection technology provide clarity and accurate monitoring in challenging conditions. The camera is also IP67-rated, making it suitable for both indoor and outdoor environments.

The H.265+ compression technology helps optimize storage usage, while the optional built-in microphone adds an extra layer of security with real-time audio monitoring. Additionally, the camera’s ability to support up to 256GB of on-board storage gives you flexibility and security for your surveillance system.

Explore More Products

Looking for more advanced surveillance solutions? Check out our range of ColorVu network cameras and bullet cameras designed for high-definition, reliable security.

Learn More

For detailed specifications and product support, visit the official product page.

Camera
Image Sensor1/3" Progressive Scan CMOS
Max. Resolution2560 × 1440
Min. IlluminationColor: 0.001 Lux @ (F1.0, AGC ON),0 Lux with light
Shutter Time1/3 s to 1/100,000 s
Day & Night24/7 color imaging
Angle AdjustmentPan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°

Lens
Lens TypeFixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV
2.8 mm, horizontal FOV: 96°, vertical FOV: 52°, diagonal FOV: 113°

4 mm, horizontal FOV: 75°, vertical FOV: 40°, diagonal FOV: 89°
Lens MountM12
Iris TypeFixed
ApertureF1.0
Depth of Field
2.8 mm: 2 m to ∞

4 mm: 2.7 m to ∞

DORI
DORI
2.8 mm, D: 64 m, O: 25 m, R: 12 m, I: 6 m

4 mm, D: 82 m, O: 32 m, R: 16 m, I: 8 m

Illuminator
Supplement Light TypeWhite Light
Supplement Light RangeUp to 30 m
Smart Supplement LightYes
Video
Main Stream
50 Hz:

20 fps (2560 × 1440)

25 fps (1920 × 1080, 1280 × 720)

60 Hz:

20 fps (2560 × 1440)

24 fps (1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)

60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360)
Video Compression
Main stream: H.265+/H.265/H.264+/H.264,

Sub-stream: H.265/H.264/MJPEG
Video Bit Rate32 Kbps to 8 Mbps
H.264 TypeBaseline Profile,Main Profile,High Profile
H.265 TypeMain Profile
Bit Rate ControlCBR,VBR
Region of Interest (ROI)1 fixed region(s) for main stream
Audio
Audio Type-U: Mono sound
Environment Noise Filtering-U: Yes
Audio Sampling Rate-U: 8 kHz/16 kHz
Audio Compression-U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
Audio Bit Rate-U: 64 Kbps (G.711 ulaw)/64 Kbps (G.711 alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)

Network
ProtocolsTCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
Simultaneous Live ViewUp to 6 channels
APIOpen Network Video Interface (Profile S, Profile T, Profile G (only -F model supports)),ISAPI,SDK
User/Host
Up to 32 users

3 user levels: administrator, operator, and user
SecurityPassword protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
ClientiVMS-4200,Hik-Connect
Web Browser
Plug-in required live view: IE 10, IE 11,

Local service: Chrome 57.0+, Firefox 52.0+

Wide Dynamic Range (WDR)120 dB
SNR≥ 52 dB
Day/Night SwitchDay,Night,Auto,Schedule
Image EnhancementBLC,HLC,3D DNR
Image SettingsRotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
Privacy Mask4 programmable polygon privacy masks

Interface
Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
Built-in Microphone-U: Yes
Reset Key-F: Yes

Event
Basic EventMotion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
LinkageUpload to FTP/memory card (-F), notify surveillance center, send email, trigger recording (-F), trigger capture

General
Power
12 VDC ± 25%, 0.4 A, max. 5 W,Ø5.5 mm coaxial power plug,

PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W
MaterialAluminum alloy body
Dimension
Ø76.6 mm × 164.4 mm (Ø3 × 6.5\")"
Package Dimension234 mm × 120 mm × 117 mm (9.2" × 4.7" × 4.6")
Weight
-L: Approx. 410 g (0.9 lb.); -LUF: Approx. 430 g (0.9 lb.)
With Package Weight
-L: Approx. 630 g (1.4 lb.); -LUF: Approx. 650 g (1.4 lb.)
Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
LanguageEnglish, Ukrainian
General FunctionHeartbeat,anti-banding,mirror,password protection,password reset via email

Approval
EMC
FCC: 47 CFR Part 15, Subpart B,

CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,

RCM: AS/NZS CISPR 32: 2015,

KC: KN32: 2015, KN35: 2015
Safety
UL: UL 62368-1,

CB: IEC 62368-1: 2014+A11,

CE-LVD: EN 62368-1: 2014/A11: 2017,

BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005
Environment
CE-RoHS: 2011/65/EU,

WEEE: 2012/19/EU,

Reach: Regulation (EC) No 1907/2006
ProtectionIP67: IEC 60529-2013
